Shenzhen Senyan Circuit Co., Ltd.
4 Years
| Ask Lasest Price | |
| Brand Name : | SenYan |
| Model Number : | multilayer pcb |
| Certification : | ISO14001,ISO13485,ISO9001,IATF16949 |
| Price : | Negotiate |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | 100000pcs |
| Delivery Time : | 1-30days |
What Can Senyan Do?
Senyan is a professional PCB / PCBA Manufacturer in China, Shenzhen. With 10 years of development, FASPCBA turns into a first class manufacturer of PCB / PCBA. From multi-layered to flexible printed circuit boards, Senyan is your one-stop shop. We provide our customers with PCB Manufacturing, PCB Assembly and Parts Sourcing service to save your time & cost.
Senyan has been selected as the “excellent partner of the year” by numerous well-known enterprises, and won many domestic and authorized certifications at home and abroad, such as Chinese high-tech project certification, ISO9001, ISO14001, ISO13485, IATF16949 quality management system standard and customized CE, UL, FCC and other product certifications according to the customer's requirements.
Millions of circuit boards are produced here every year, which provides superior service for automotive electronics, medical electronics, power communications, industrial automation, millitary, aviation & aerospace, intelligent home and other industries around the world. We will continue to improve our quality and service; customer satisfaction and development of science and technology are our eternal motivation.
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board Cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) | |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” | |
| 4layer:0.01±0.008” | ||
| 8layer:0.01±0.008” | ||
| Bow and twist | no more than 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z | |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) | |
| PTH hole tolerance | ±0.002″(0.005mm) | |
| NPTH hole tolerance | ±0.002″(0.005mm) | |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) | |
| Thickness | (0.012*0.017mm) | |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) | |
| Component Sourcing | Yes | |
| Tolerance of PCB | ±5% | |
| Max Size of Finish Board | 700*460mm | |
| MOQ | NO MOQ (1pcs) | |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
| PCB Outline | Square,circle,irregular(with jigs) | |
| Package | QFN,BGA,SSOP,PLCC,LGA | |
| Sub-assembly | Plastic,metal,screen | |
| Min Line/Space | 0.075/0.075mm | |
As a 10 years PCB manufacturer in China, FASTPCBA is providing the latest printed circuit board technologies and highest quality standards for electronics industry. You can trust us to meet your demands, from small volume to mass production whatever the simplest PCB boards or the most complex.
10 Years Experience
Accept Stardard: IPC III, Military, Automotive, Medcial, We offer
you expanded PCB capabilities: Rigid PCB, Flexible, Rigid-flex, HDI
board, High TG PCB
Up to 48 layer prototype PCB
Manufacture PCB board up to 56 layer, Raw material: Fr4, Rogers,
Arlon, Teflon, Taconic, Nelco, Isola, Ceramic, Metal core
Up to 18 layer mass production
Support PCB surface process: HASL-LF, ENIG, Plating gold, Immersion
tin, Immersion silver, ENIPIG, OSP
1. PCB:Pleasep provide gerber file for detail Quote.
2. PCBA:Please provide gerder file and Bom list.
3. COPY PCB/PCBA:Please provide us the details of PCB.Picture and
Sample will be better.
1. We need to confirm PCB requirements and components.
2. PCB quote will be offered within 24 hours.
3. PCBA quote will be offered within 2 working day.
We provide one-stop PCB/PCBA customization services. To meet all of customer's PCB/PCBA requirement is Senyan circuit service's goal
1. To offer good quality PCB/PCBA to our customer, we will do many kind of testing to ensure quality before shipment
2. Outgoing test to check min PTH Cu thickness, Min surface Cu thickness, ENIG Au data,Ni data, Au layer adhesion testing, soldermask adhesion testing, silkscreen adhesion testing, Thermal stress testing, hardness testing, Twist testing, Bow testing
3. Microsection testing to check hole Cu thickness, Surface Copper thickness, Wrap copper thickness, Hole Wall Integrity, soldermask thickness and stack up.
4. E-test to check any open/short circuit.
5. Thermal Stress Test to avoid any Delamination, Measling and others.
6. Solderability of PTH to avoid any discolor, Wrinkles, Blisters, Measling, Blow-Hole, Solermask peel off, and soldermask filled in hole-wall incompletely.
Impedance testing, and so on……
Please feel free to contact with us!
FAQ
Q: What does Senyan need for a customized PCB order?
A: When you place a PCB order, the customers need to provide Gerber or pcb file.If you do not have the file in the correct format,
Q: What is your quotation policy?
A: For the PCB order in large quantity, Senyan will send you the quotation based on the MOQ of the products concerned, and the price will be reasonable with good quality.
Q: What does Senyan need for other services?
A: For PCB clone service, the customer needs to send us the printed circuit board concerned,and also the sharp photos of its front side and the back side.
Q: How about the service Senyan offered to the customers?
A: If you have any questions about our products or company, do not hesitate to send us your inquiry toour customer service representatives, Your satisfaction is our pursuits.
|
|
