Shenzhen Senyan Circuit Co., Ltd.
4 Years
| Ask Lasest Price | |
| Brand Name : | SenYan |
| Model Number : | PCB Assembly |
| Certification : | ISO14001,ISO13485,ISO9001,IATF16949 |
| Price : | Negotiate |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | 100000pcs |
| Delivery Time : | 1-30days |
| 1 | Material | FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material, PI Material, BT Material, PPO, PPE etc. |
| 2 | Board thickness | Mass production: 394mil(10mm) Samples: 17.5mm |
| 3 | Surface finish | HASL, OSP, Immersion Silver, Immersion Gold, ENIG, ENEPIG, Immersion Tin |
| 4 | PCB Max panel size | 1190*350mm/450*450mm |
| 5 | Layer | Samples: 1-64 Layers, Mass production: 2-58 Layers, Flexible PCB: 1-12 Layers |
| 6 | Min.drilled hole size | Machine Drilling 8mil(0.20mm), Laser Drilling 3mil(0.075mm) |
| 7 | PCBA QC | X-ray, AOI Test, Functional Test |
| 8 | Specialty | Gateway, Medical, Security, GPS tracker, Consumer, Automotive electronics |
| 9 | Our service | PCB, Turnkey PCBA, PCB Clone, Housing, PCB Assembly, Component sourcing, PCB development and design, PCB manufacturing from 1 to 64 layers |
| 10 | Sanforized | Buried via, Blind via, Mixed Pressure, Embedded Resistance, Embedded Capacitance, Local Mixed Pressure, Local High Density, Back drill, impedance control. |
| 11 | Certificate | RoHS/ISO9001/TS16949/UL/ISO14001/ISO13485 |
Your Troubles | Our Strategy | |||
Lack of engineering experience Various unexpected problems, causing the project to fail | Rich engineering experience: Bom Engineer/ Product Engineer/
Technical Engineer /Purchasing Engineer.Eliminate Problems and
pitfalls at the design stage | |||
Coordinating multiple suppliers Insufficient time and energy | PCB Assembly and welding factory, Component procurement
team,Function Test , Finished Product Assembly. Provide one-stop
service, save time and worry | |||
Product quality control High hardware trial and error cost | Rigorous process and strong strength We have established a standardized and rigorous process and system
to effectively reduce quality problems | |||
Traders do not have physical factories The quality is not guaranteed, Documents easy to disclose | Own teams and factory, the delivery time is more controllable | |||
Hard delivery guarantee The market can't wait | Complete Organizational Structure: Project Department, Engineering
Department, Purchasing Department, Quality Department, Production Department, Etc. | |||
Welcome to Senyan
Senyan was established in 2006. We mainly offer High-Precision
Single-Side, Double-Side, Multi-layer Printed Circuit Boards, LED
Aluminium Printed Circuit Board, Customers Components Procurement
and PCB Assembly (SMT) Business.
Now the production capacity of our factory has reached 100,000
square meters annually. And our products apply far and wide in many
fields such as communication, computer, mobile phone, electronic
equipment, and electrical appliance.
1. specifications
1. We offer One-shop PCAB/PCB manufacturing service
2.10 year of turnkey ODM/OEM experience
3. We can provide F4B,F4BK, Teconic,Arlon,Rogers materia PCB
4. Timely customizations PCBs and PCBAs
2. Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technolog
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Assembly With UL,CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity
SMT Manufacturing Capability | |||
Item | Manufacturing Capability in process | Manufacturing Method | |
Production size(Min/Max) | 50×50mm / 500×500mm | ||
Production board thickness | 0.2 ～ 4mm | ||
Printing solder paste | Support method | Magnetism fixture, vacuo platform | |
Clamping method | Sticking up by vacuo, clamping on both sides ,flexible clamping
with sheet, flexible clamping with thick board | ||
Cleaning Method of printing solder paste | Dry method+ wetting method+ Vacuo method | ||
Accuracy of printing | ±0.025mm | ||
SPI | Repeated accuracy of volume | <1% at 3σ | |
Mounting component | Components size | 0603(Option) L75mm Connector | |
Pitch | 0.15mm | ||
Repeated accuracy | ±0.01mm | ||
AOI | FOV size | 61×45mm | |
Test speed | 9150mm²/Sec | ||
3D X-ray | Shootingangle | 0-45 | |
Rigid RPCB Manufacturing Capability | ||
Item | RPCB | HDI |
minimum linewidth/linespacing | 3MIL/3MIL(0.075mm) | 2MIL/2MIL(0.05MM) |
minimum hole diameter | 6MIL(0.15MM) | 6MIL(0.15MM) |
minimum solder resist opening (single-side) | 1.5MIL(0.0375MM) | 1.2MIL(0.03MM) |
minimum solder resist bridge | 3MIL(0.075MM) | 2.2MIL(0.055MM) |
maximum aspect Ratio (thickness/hole diameter) | 10:1 | 8:1 |
impedance control accuracy | +/-8% | +/-8% |
finished thickness | 0.3-3.2MM | 0.2-3.2MM |
maximum board size | 630MM*620MM | 620MM*544MM |
maximum finished copper thickness | 6OZ(210UM) | 2OZ(70UM) |
minimum board thickness | 6MIL(0.15MM) | 3MIL(0.076MM) |
maximum layer | 14层 | 12层 |
Surface treatment | HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag | Immersion Gold,OSP,selectiveimmersion gold, carbon print |
Min/max laser hole size | / | 3MIL / 9.8MIL |
laser hole size tolerance | / | 10% |
FAQ
Q1.What is needed for quotation?
A: PCB Circuit Boards: Quantity, Gerber file and Technic
requirements(material,surface finish treatment, copper
thickness,board thickness ,...)
PCBA: PCB information, BOM, (Testing documents...)
Q2. What file formats do you accept for production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security.We protect
the intellectual property for our customers in the whole process..
All documents from customers are never shared with any third
parties.
Q4. MOQ?
A: We accept small order,1PCS is available.We are able to handle
Small as well as large volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight,
packing size of the goods. Please let us know if you need us to
quote you the shipping cost.
|
|
