Senyan has the capability to manufacture pcb ranging from basic
single sided boards up to twenty-two layer multilayers ,and provide
one stop turnkey services, including pcb layout, manufacture,
assembly, components sourcing and function testing. The superior
service we offer our customers is the key to our success and our
mission has remained the same since we started business in 2006: to
provide high quality, technically advanced products within the
customer’s timescales. This commitment, combined with the wealth of
experience and expertise we have built up over the years, means we
can offer a total solution to our customers PCB requirements – from
front end engineering through to in time deliveries.
| Article | Description | Capability |
| Laminate Materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board Cutting | Number of layers | 1-48 |
| Min.thickness for inner layers (Cu thickness are excluded) | 0.003”(0.07mm) | |
| Board Thickness | Standard | (0.1-4mm±10%) |
| Min. | Single/Double:0.008±0.004” | |
| 4layer:0.01±0.008” | ||
| 8layer:0.01±0.008” | ||
| Bow and twist | no more than 7/1000 | |
| Copper Weight | Outer Cu weight | 0.5-4 0z |
| Inner Cu weight | 0.5-3 0z | |
| Drilling | Min size | 0.0078”(0.2mm) |
| Drill deviation | ±0.002″(0.05mm) | |
| PTH hole tolerance | ±0.002″(0.005mm) | |
| NPTH hole tolerance | ±0.002″(0.005mm) | |
| Solder Mask | Color | Green,white,black,red,blue… |
| Min solder mask clearanace | 0.003″(0.07mm) | |
| Thickness | (0.012*0.017mm) | |
| Silkscreen | Color | white,black,yellow,blue… |
| Min size | 0.006″(0.15mm) | |
| Component Sourcing | Yes | |
| Tolerance of PCB | ±5% | |
| Max Size of Finish Board | 700*460mm | |
| MOQ | NO MOQ (1pcs) | |
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | |
| PCB Outline | Square,circle,irregular(with jigs) | |
| Package | QFN,BGA,SSOP,PLCC,LGA | |
| Sub-assembly | Plastic,metal,screen | |
| Min Line/Space | 0.075/0.075mm | |
1. PCB:Pleasep provide gerber file for detail Quote.
2. PCBA:Please provide gerder file and Bom list.
3. COPY PCB/PCBA:Please provide us the details of PCB.Picture and
Sample will be better.
1. We need to confirm PCB requirements and components.
2. PCB quote will be offered within 24 hours.
3. PCBA quote will be offered within 2 working day.
LAYER | PROTOTYPE | MASS PRODUCTION (above 30 m2) | |
Quick Turn | Usual Time | ||
2 | 24 hours | 3-4 days | 8-10 days |
4 | 48 hours | 5-6 days | 10-12 days |
6 | 72 hours | 6-8 days | 12-14 days |
8 | 72 hours | 8-10 days | 16-18 days |
10 | 96 hours | 12-12 days | 18-20 days |
....... | ...... | ....... | ....... |
