Welcome to Senyan, we focus on PCBA manufacturer since 2006, welcome send us your Gerber file and BOM to custom your PCBA or electronic complete productio
Our Advantages&Service
1. PCB Making(Rigid, Flexible, rigid-flexible, Aluminium, High TG,
ceramic),Component Source(We have the good supply chain to ensure quality
with competitive price), SMT&DIP, Free Programe&Test, OEM service.
2. Factory Area: 10000square meters, 400workers, 13 SMT Lines, 5 DIP Lines, 1 X-ray, 13 AOI machines, 2 Sample test machine.
3. Certification : UL, CE, FCC, RoHS, ISO9001, ISO14001, ISO13485, TS16949
4. Quality Control: IPC-A-610E standard, E-test, X-ray, AOI test, IQC, QC, QA, 100% functional test.
5. Quote within 24 Hours.
| 1 | Material | FR4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material, PI Material, BT Material, PPO, PPE etc. |
| 2 | Board thickness | Mass production: 394mil(10mm) Samples: 17.5mm |
| 3 | Surface finish | HASL, OSP, Immersion Silver, Immersion Gold, ENIG, ENEPIG, Immersion Tin |
| 4 | PCB Max panel size | 1190*350mm/450*450mm |
| 5 | Layer | Samples: 1-64 Layers, Mass production: 2-58 Layers, Flexible PCB: 1-12 Layers |
| 6 | Min.drilled hole size | Machine Drilling 8mil(0.20mm), Laser Drilling 3mil(0.075mm) |
| 7 | PCBA QC | X-ray, AOI Test, Functional Test |
| 8 | Specialty | Gateway, Medical, Security, GPS tracker, Consumer, Automotive electronics |
| 9 | Our service | PCB, Turnkey PCBA, PCB Clone, Housing, PCB Assembly, Component sourcing, PCB development and design, PCB manufacturing from 1 to 64 layers |
| 10 | Sanforized | Buried via, Blind via, Mixed Pressure, Embedded Resistance, Embedded Capacitance, Local Mixed Pressure, Local High Density, Back drill, impedance control. |
| 11 | Certificate | RoHS/ISO9001/TS16949/UL/ISO14001/ISO13485 |
SMT Manufacturing Capability | |||
Item | Manufacturing Capability in process | Manufacturing Method | |
Production size(Min/Max) | 50×50mm / 500×500mm | ||
Production board thickness | 0.2 ～ 4mm | ||
Printing solder paste | Support method | Magnetism fixture, vacuo platform | |
Clamping method | Sticking up by vacuo, clamping on both sides ,flexible clamping
with sheet, flexible clamping with thick board | ||
Cleaning Method of printing solder paste | Dry method+ wetting method+ Vacuo method | ||
Accuracy of printing | ±0.025mm | ||
SPI | Repeated accuracy of volume | <1% at 3σ | |
Mounting component | Components size | 0603(Option) L75mm Connector | |
Pitch | 0.15mm | ||
Repeated accuracy | ±0.01mm | ||
AOI | FOV size | 61×45mm | |
Test speed | 9150mm²/Sec | ||
3D X-ray | Shootingangle | 0-45 | |
Rigid RPCB Manufacturing Capability | ||
Item | RPCB | HDI |
minimum linewidth/linespacing | 3MIL/3MIL(0.075mm) | 2MIL/2MIL(0.05MM) |
minimum hole diameter | 6MIL(0.15MM) | 6MIL(0.15MM) |
minimum solder resist opening (single-side) | 1.5MIL(0.0375MM) | 1.2MIL(0.03MM) |
minimum solder resist bridge | 3MIL(0.075MM) | 2.2MIL(0.055MM) |
maximum aspect Ratio (thickness/hole diameter) | 10:1 | 8:1 |
impedance control accuracy | +/-8% | +/-8% |
finished thickness | 0.3-3.2MM | 0.2-3.2MM |
maximum board size | 630MM*620MM | 620MM*544MM |
maximum finished copper thickness | 6OZ(210UM) | 2OZ(70UM) |
minimum board thickness | 6MIL(0.15MM) | 3MIL(0.076MM) |
maximum layer | 14层 | 12层 |
Surface treatment | HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag | Immersion Gold,OSP,selectiveimmersion gold, carbon print |
Min/max laser hole size | / | 3MIL / 9.8MIL |
laser hole size tolerance | / | 10% |
1. What is your MOQ?
We support OEM orders, No MOQ for any order, sample order also welcomed.
2. How can we get an accurate offer?
Please send us your Gerber file and BOM list, we will quote for you within 24hours.
3. What is the guarantee of quality? What are the certifications?
The guarantee is 2 year; Products passed ISO14001, ROHS, ISO9001, TS16949, ISO13485, UL.
4. What are the hardware conditions of your factory?
We have 13 SMT lines and 5 DIP lines, more than 400 workers.
5. How long is my project delivery?
Mass productions:
1-2L: 3-7 days
4-8L: 7-10 days
10-18L: 10-15 days
Samples:
1-2L: 2-3 days
4-8L: 2-7 days
10-18L: 4-9 days
Quick samples: 24H/48H
6. What service do you offer?
Design, Layout, PCB Fabrication, PCBA Assembly, Components Sourcing, Function Testing.
7. What are the main products of your PCB/PCBA service?
Our main production has IoT&Gateway, Medical, Security, Consumer, LED, industrial control, we are able to make all of PCBA which you can provide Gerber file and BOM.
|
|
