PCBA Electronic Circuit Board Manufacturer 94v0 ROHS PCB Supplier Other PCB And PCBA Fabrication

Files and Requirment for PCB,PCBA quotation:

• A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
• PCB Gerber files.
• A PCB fabrication drawing and PCBA assembly drawing.
• Test procedures.
• Any mechanical restrictions such as assembly height requirements

• PCB board manufacture and PCBA service:
  • o PCB board made, circuit board parts purchased by us
  • o Electronic testing circuit board or PCBA
  • o Fast delivery, anti-static package
  • o RoHS Directive-compliant, lead-free
  • o One stop service from PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
  • o Eleectronic manufacturing service
• Detailed terms for PCB assembly:
  • o Technical requirement:
    • § Professional surface-mounting and through-hole soldering technology
    • § Various sizes like 1206, 0805, 0603 components SMT technology
    • § ICT (In Circuit Test), FCT (Functional Circuit Test) technology
    • § PCB assembly with UL, CE, FCC, RoHS approval
    • § Nitrogen gas reflow soldering technology for SMT
    • § High standard SMT and solder assembly line
    • § High density interconnected board placement technology capacity
  • o Quote requirement:
    • § Gerber file and Bom list
    • § Clear pics of pcba or pcba sample for us
    • § Test method for PCBA
  • o PCB specification:
    • § Layer: 1 to 12 layers
    • § Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
    • § Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25″)
    • § Max. finished board side: 500 x 500mm (20 x 20”)
    • § Min. drilled hole size: 0.25mm (10mil)
    • § Min. line width: 0.10mm (4mil)
    • § Min. line spacing: 0.10mm (4mil)
    • § Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
    • § Copper thickness: 0.5 to 3.0 oz
    • § Solder mask color: green/black/white/red/blue
    • § Inner packing: plastic bag
    • § Outer packing: standard carton packing
    • § Hole tolerance: PTH: ±0.076, NTPH: ±0.05
    • § Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
    • § Profiling punching: routing, V-cut, beveling
    • § Providing OEM service to all sorts of printed circuit board assemb

SMT Manufacturing Capability

Q1.What is needed for PCB PCBA quotation?

PCB(printed circuit board): Quantity, Gerber file and Technic requirements(material,surface finish treatment, copper thickness,board thickness ,...)

PCBA(printed circuit board assembly): PCB information, BOM, (Testing documents...)

Q2. What file formats do you accept for PCB PCBA production?

Gerber file: CAM350 RS274X

PCB file: Protel 99SE, P-CAD 2001 PCB

BOM: Excel (PDF,word,txt)

Q3. Are my files safe?

Your files are held in complete safety and security.We protect the intellectual property for our customers in the whole process.. All documents from customers are never shared with any third parties.

We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.

Q4. MOQ?

There is no MOQ (PCBA shenzhen).We are able to handle Small as well as large volume production with flexibility.

Q5.Shipping cost?

The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

Q6. What service do you have?
A: We mainly focus on PCB+Assembly+Components sourcing service. Additionally, we can also provide programming, testing, cables, enclosure assembly service.

Q7. Can we inspect quality during production?

Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house.

Q8. No PCB file/Gbr file, only have the PCB sample,can you produce it for me?

Yes,we could help you to clone the PCB. Just send the sample PCB to us, we could clone the PCB design and work out it.

Q9. Which countries have you worked with?

US, Canada, Italy, Germany, Czech Republic, Australia, Japan, and so on.

Q9. What is your testing policy and how you controle the quality?

For sample, usually tested by flying probe; for PCB Volume over 3 square meters, usually tested by fixture, this will be more faster. Due to there’s many steps to PCB production, we usually do inspection after every step.

Shenzhen SenYan Circuit Co.,Ltd. , a professional PCB company, specialize in the single-sided, double-sided and multilayer boards manufacturing .We also carry on SMT,DIP processing and other special requirement PCBs,such as high precision half orifice circuit boards, impedance circuit boards and buried blind hole circuit boards.

Since the establishment in 2006,our company has introduced advanced production and testing equipment from Taiwan and Germany, and employed experienced managers and technical backbones.The product quality strictly complies with IPC standard and American military MIL standard.The company has attained the UL security certification, ISO9001-2000 quality system certification and ISO14001 environmental system certification.After years of development,the company has expanded rapidly, and has been recognized and supported by customers and industries from all walks of life.
