    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz

    Ask Lasest Price
    Brand Name : SenYan
    Model Number : PCB manufacturing
    Certification : ISO14001,ISO13485,ISO9001,IATF16949
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 100000pcs
    Delivery Time : 1-30days
    • Product Details
    • Company Profile

    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz

    PCB manufacturing manufacture PCB Assembly Fast PCBA service in China Customization Service manufacturer SMT

    Place of Origin: Guangdong, China
    Copper Thickness: 0.5
    Board Thickness: 1.5
    Type:Control board
    Application:Anet 3D Printer
    Weight: 0.5KG
    Package:Standard Package

    Senyan is China PCB assembly manufacturer ,who offers complete PCB services in Shenzhen , Senyan‘s capable of providing turn-key and partial turn-key printed circuit board assembly services.


    For full turn-key, we take care of the entire process, including manufacturing of Printed Circuit Boards, procurement of components (100% original) , PCBA Testing , continuous monitoring of quality and final assembly.


    Flexible Volume Assembly Alternatives:
    Prototype PCB Assembly
    Low-Volume, High Mix PCB Assembly
    High-Volume PCB Assembly
    Consigned & Partial PCB Assembly
    Full Turnkey PCB Assembly
    Cable & Wire Harness Assembly
    Box Build Assembly Services

    Our Services & Strength

    > Factory workshop area of 4000 square meters
    > Employees:200, including 10 senior technicians
    > OEM one stop service :from pcba to finished products
    > 6 SMD machine lines, 6 million points capacity per day
    > 4 DIP lines and 25K PCBAs per day.
    > 4 assembly lines and 3-7K finished products per day.
    We help
    Your Troubles
    Our Strategy
    Lack of engineering experience
    Various unexpected problems, causing the project to fail
    Rich engineering experience: Bom Engineer/ Product Engineer/ Technical Engineer /Purchasing Engineer.Eliminate Problems and pitfalls at the design stage
    Coordinating multiple suppliers
    Insufficient time and energy
    PCB Assembly and welding factory, Component procurement team,Function Test , Finished Product Assembly. Provide one-stop service, save time and worry
    Product quality control
    High hardware trial and error cost
    Rigorous process and strong strength
    We have established a standardized and rigorous process and system to effectively reduce quality problems
    Traders do not have physical factories
    The quality is not guaranteed, Documents easy to disclose
    Own teams and factory, the delivery time is more controllable
    Hard delivery guarantee
    The market can't wait
    Complete Organizational Structure: Project Department, Engineering Department, Purchasing Department, Quality Department,
    Production Department, Etc.

    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz

    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz

    Professional China Aluminum LED PCB Board Manufacturing SMD2835 LED PCB Circuit Board
    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz
    SMT Manufacturing Capability
    SMT Manufacturing Capability
    Item
    Manufacturing Capability in process
    Manufacturing Method
    Production size(Min/Max)
    50×50mm / 500×500mm
    Production board thickness
    0.2 ~ 4mm
    Printing solder paste
    Support method
    Magnetism fixture, vacuo platform
    Clamping method
    Sticking up by vacuo, clamping on both sides ,flexible clamping with sheet, flexible clamping with thick board
    Cleaning Method of printing solder paste
    Dry method+ wetting method+ Vacuo method
    Accuracy of printing
    ±0.025mm
    SPI
    Repeated accuracy of volume
    <1% at 3σ
    Mounting component
    Components size
    0603(Option) L75mm Connector
    Pitch
    0.15mm
    Repeated accuracy
    ±0.01mm
    AOI
    FOV size
    61×45mm
    Test speed
    9150mm²/Sec
    3D X-ray
    Shootingangle
    0-45
    Rigid RPCB Manufacturing Capability
    Rigid RPCB Manufacturing Capability
    Item
    RPCB
    HDI
    minimum linewidth/linespacing
    3MIL/3MIL(0.075mm)
    2MIL/2MIL(0.05MM)
    minimum hole diameter
    6MIL(0.15MM)
    6MIL(0.15MM)
    minimum solder resist opening (single-side)
    1.5MIL(0.0375MM)
    1.2MIL(0.03MM)
    minimum solder resist bridge
    3MIL(0.075MM)
    2.2MIL(0.055MM)
    maximum aspect Ratio (thickness/hole diameter)
    10:1
    8:1
    impedance control accuracy
    +/-8%
    +/-8%
    finished thickness
    0.3-3.2MM
    0.2-3.2MM
    maximum board size
    630MM*620MM
    620MM*544MM
    maximum finished copper thickness
    6OZ(210UM)
    2OZ(70UM)
    minimum board thickness
    6MIL(0.15MM)
    3MIL(0.076MM)
    maximum layer
    14层
    12层
    Surface treatment
    HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag
    Immersion Gold,OSP,selectiveimmersion gold,
    carbon print
    Min/max laser hole size
    /
    3MIL / 9.8MIL
    laser hole size tolerance
    /
    10%
    Our Services

    Fast PCBA SMT Printed Circuit Board Assembly 1.5mm 1oz


    electronic 2 layer pcb,china pcb factory

    Q: What service do you have?
    Senyan: We provide turnkey solution including PCB fabrication, SMT, plastic injection & metal,final assembly, testing and othervalue-added service.
    Q: What is needed for PCB & PCBA quotation?
    Senyan: For PCB: Quantity, Gerber file and technic requirements(material,size, surface finish treatment, copper thickness,board thickness).

    Q: What are the main products of your PCB/PCBA services?
    Senyan: Automotive, Medical, Industry Control, IOT, Smart Home, Military, Aerospace.
    Q: How to keep our product information and design file secret ?
    Senyan: We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.

    Q: What is your minimum order quantity (MOQ)?
    Senyan: Our MOQ is 1 PCS, sample and mass production all can support.
    Q: Are you factory?
    Senyan: Our factory is located in Shenzhen China
    We offer instant quotes for your turnkey PCB assembly order and you don’t need to wait for long to know how much the order would cost. Also, you can see the real-time status of your project. This helps you to monitor the PCB manufacturing stage. With a single point of contact, and flexible services, FASTPCBA’s full turnkey electronics assembly meets the unique needs of small businesses, large corporations, and entrepreneurs. You can upload your GERBER & BOM to receive a quote.
