China Aluminum LED Bulb PCB SMD LED PCB Circuit Board Used For DOB bulb light

SMT Manufacturing Capability

SMT Manufacturing Capability
Item		Manufacturing Capability in process	Manufacturing Method
Production size(Min/Max)		50×50mm / 500×500mm
Production board thickness		0.2 ～ 4mm
Printing solder paste	Support method		Magnetism fixture, vacuo platform
	Clamping method		Sticking up by vacuo, clamping on both sides ,flexible clamping with sheet, flexible clamping with thick board
	Cleaning Method of printing solder paste		Dry method+ wetting method+ Vacuo method
	Accuracy of printing	±0.025mm
SPI	Repeated accuracy of volume	<1% at 3σ
Mounting component	Components size	0603(Option) L75mm Connector
	Pitch	0.15mm
	Repeated accuracy	±0.01mm
AOI	FOV size	61×45mm
	Test speed	9150mm²/Sec
3D X-ray	Shootingangle	0-45

Rigid RPCB Manufacturing Capability

Rigid RPCB Manufacturing Capability
Item	RPCB	HDI
minimum linewidth/linespacing	3MIL/3MIL(0.075mm)	2MIL/2MIL(0.05MM)
minimum hole diameter	6MIL(0.15MM)	6MIL(0.15MM)
minimum solder resist opening (single-side)	1.5MIL(0.0375MM)	1.2MIL(0.03MM)
minimum solder resist bridge	3MIL(0.075MM)	2.2MIL(0.055MM)
maximum aspect Ratio (thickness/hole diameter)	10:1	8:1
impedance control accuracy	+/-8%	+/-8%
finished thickness	0.3-3.2MM	0.2-3.2MM
maximum board size	630MM*620MM	620MM*544MM
maximum finished copper thickness	6OZ(210UM)	2OZ(70UM)
minimum board thickness	6MIL(0.15MM)	3MIL(0.076MM)
maximum layer	14	12
Surface treatment	HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag	Immersion Gold,OSP,selectiveimmersion gold, carbon print
Min/max laser hole size	/	3MIL / 9.8MIL
laser hole size tolerance	/	10%

Our Services

Q: Are you trading company or manufacturer ?
A: We are PCB manufacturer with 10 years experience in this area.

Q: What is your minimum order quantity?
A: MOQ is 5 PCS.

Q: What is your advandage than other supplier ?
A: We have around 10 years of experience in produce PCB,with professional engineer team and advanced auto production line.

Q: How about your supply capacity?
A: Our supply capacity is around 2000sqm each day. where our 25 000 sqm factory space hosts R&D, marketing, logistics and procurement operations.

Q: How can I get a sample to check your quality?
A: After price confirmation,you can place orders for samples for your testing and evaluation.

Q: How long can I receive the sample?
A: After you make a payment and send us confirmed files,your samples will be ready within 3-5 work days. If there are some urgent orders,we can produce with within 48 hours with an extra express fee.

Q: What about the transportation and delivery date?
A: Normally,we use international express(such as,Fedex,DHL,TNT) to deliver samples and small volume orders. For large mass order, we can arrange shipping by sea.

Shenzhen SenYan Circuit Co.,Ltd. , a professional PCB company, specialize in the single-sided, double-sided and multilayer boards manufacturing .We also carry on SMT,DIP processing and other special requirement PCBs,such as high precision half orifice circuit boards, impedance circuit boards and buried blind hole circuit boards.

Since the establishment in 2006,our company has introduced advanced production and testing equipment from Taiwan and Germany, and employed experienced managers and technical backbones.The product quality strictly complies with IPC standard and American military MIL standard.The company has attained the UL security certification, ISO9001-2000 quality system certification and ISO14001 environmental system certification.After years of development,the company has expanded rapidly, and has been recognized and supported by customers and industries from all walks of life.
