Shenzhen Senyan Circuit Co., Ltd.
4 Years
| Ask Lasest Price | |
| Brand Name : | SenYan |
| Model Number : | aluminum PCB |
| Certification : | ISO14001,ISO13485,ISO9001,IATF16949 |
| Price : | Negotiate |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | 100000pcs |
| Delivery Time : | 1-30days |
SMT Manufacturing Capability | |||
Item | Manufacturing Capability in process | Manufacturing Method | |
Production size(Min/Max) | 50×50mm / 500×500mm | ||
Production board thickness | 0.2 ～ 4mm | ||
Printing solder paste | Support method | Magnetism fixture, vacuo platform | |
Clamping method | Sticking up by vacuo, clamping on both sides ,flexible clamping
with sheet, flexible clamping with thick board | ||
Cleaning Method of printing solder paste | Dry method+ wetting method+ Vacuo method | ||
Accuracy of printing | ±0.025mm | ||
SPI | Repeated accuracy of volume | <1% at 3σ | |
Mounting component | Components size | 0603(Option) L75mm Connector | |
Pitch | 0.15mm | ||
Repeated accuracy | ±0.01mm | ||
AOI | FOV size | 61×45mm | |
Test speed | 9150mm²/Sec | ||
3D X-ray | Shootingangle | 0-45 | |
Rigid RPCB Manufacturing Capability | ||
Item | RPCB | HDI |
minimum linewidth/linespacing | 3MIL/3MIL(0.075mm) | 2MIL/2MIL(0.05MM) |
minimum hole diameter | 6MIL(0.15MM) | 6MIL(0.15MM) |
minimum solder resist opening (single-side) | 1.5MIL(0.0375MM) | 1.2MIL(0.03MM) |
minimum solder resist bridge | 3MIL(0.075MM) | 2.2MIL(0.055MM) |
maximum aspect Ratio (thickness/hole diameter) | 10:1 | 8:1 |
impedance control accuracy | +/-8% | +/-8% |
finished thickness | 0.3-3.2MM | 0.2-3.2MM |
maximum board size | 630MM*620MM | 620MM*544MM |
maximum finished copper thickness | 6OZ(210UM) | 2OZ(70UM) |
minimum board thickness | 6MIL(0.15MM) | 3MIL(0.076MM) |
maximum layer | 14层 | 12层 |
Surface treatment | HASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag | Immersion Gold,OSP,selectiveimmersion gold, carbon print |
Min/max laser hole size | / | 3MIL / 9.8MIL |
laser hole size tolerance | / | 10% |
Q1.What is needed for PCB PCBA quotation?
A: PCB: Quantity, Gerber file and Technic
requirements(material,surface finish treatment, copper
thickness,board thickness ,...)
PCBA: PCB information, BOM, (Testing documents...)
Q2. What file formats do you accept for PCB PCBA production?
A: Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)
Q3. Are my files safe?
A: Your files are held in complete safety and security.We protect
the intellectual property for our customers in the whole process..
All documents from customers are never shared with any third
parties.
Q4. MOQ?
A: There is no MOQ.We are able to handle Small as well as large
volume production with flexibility.
Q5.Shipping cost?
A: The shipping cost is determined by the destination, weight,
packing size of the goods. Please let us know if you need us to
quote you the shipping cost.
Q6: What service do you have?
A:We can offer one-stop service from PCB manufacturing to PCB assembling, testing,housing and other value-added service.
|
|
