1-30 Layer Aluminum LED Light Bulb Circuit Board

Shenzhen Senyan Circuit Co., Ltd.
Contact Now
    Buy cheap 1-30 Layer Aluminum LED Light Bulb Circuit Board from wholesalers

    Buy cheap 1-30 Layer Aluminum LED Light Bulb Circuit Board from wholesalers
    • Buy cheap 1-30 Layer Aluminum LED Light Bulb Circuit Board from wholesalers

    1-30 Layer Aluminum LED Light Bulb Circuit Board

    Ask Lasest Price
    Brand Name : SenYan
    Model Number : aluminum PCB
    Certification : ISO14001,ISO13485,ISO9001,IATF16949
    Price : Negotiate
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 100000pcs
    Delivery Time : 1-30days
    • Product Details
    • Company Profile

    1-30 Layer Aluminum LED Light Bulb Circuit Board

    Aluminum PCB Shenzhen Factory Electronical Led Circuit Board Reverse Engineering Led Bulb Aluminum Pcb


    We produce 1-2 layer metal substrate PCB, and 1-30 layer rigid PCB.

    For metal substrate PCB, we're professional at aluminum pcb,and copper pcb board.
    SMT Manufacturing Capability
    SMT Manufacturing Capability
    Item
    Manufacturing Capability in processManufacturing Method
    Production size(Min/Max)50×50mm / 500×500mm
    Production board thickness0.2 ~ 4mm
    Printing solder paste
    Support methodMagnetism fixture, vacuo platform
    Clamping methodSticking up by vacuo, clamping on both sides ,flexible clamping with sheet, flexible clamping with thick board
    Cleaning Method of printing solder pasteDry method+ wetting method+ Vacuo method
    Accuracy of printing±0.025mm
    SPIRepeated accuracy of volume<1% at 3σ
    Mounting component
    Components size0603(Option) L75mm Connector
    Pitch0.15mm
    Repeated accuracy±0.01mm
    AOI
    FOV size61×45mm
    Test speed9150mm²/Sec
    3D X-rayShootingangle0-45
    Rigid RPCB Manufacturing Capability
    Rigid RPCB Manufacturing Capability
    Item
    RPCB
    HDI
    minimum linewidth/linespacing
    3MIL/3MIL(0.075mm)
    2MIL/2MIL(0.05MM)
    minimum hole diameter
    6MIL(0.15MM)
    6MIL(0.15MM)
    minimum solder resist opening (single-side)
    1.5MIL(0.0375MM)
    1.2MIL(0.03MM)
    minimum solder resist bridge3MIL(0.075MM)
    2.2MIL(0.055MM)
    maximum aspect Ratio (thickness/hole diameter)
    10:1
    8:1
    impedance control accuracy
    +/-8%+/-8%
    finished thickness0.3-3.2MM
    0.2-3.2MM
    maximum board size630MM*620MM620MM*544MM
    maximum finished copper thickness6OZ(210UM)2OZ(70UM)
    minimum board thickness6MIL(0.15MM)3MIL(0.076MM)
    maximum layer14
    12
    Surface treatmentHASL-LF,OSP ,Immersion Gold, Immersion Tin ,Immersion Ag
    Immersion Gold,OSP,selectiveimmersion gold,
    carbon print
    Min/max laser hole size/
    3MIL / 9.8MIL
    laser hole size tolerance/
    10%
    Electronic LED MCPCB Aluminum PCB Board, Printed Circuit Board Assembly, PCB Manufacturer
    1-30 Layer Aluminum LED Light Bulb Circuit Board
    1-30 Layer Aluminum LED Light Bulb Circuit Board
    1-30 Layer Aluminum LED Light Bulb Circuit Board
    Our Services

    1-30 Layer Aluminum LED Light Bulb Circuit Board


    1-30 Layer Aluminum LED Light Bulb Circuit Board

    Q1. Can I have a sample order to test it?
    A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

    Q2. What about the lead time?
    A:Sample needs 3-5 days, mass production time needs 8-12 days.

    Q3. Do you have MOQ for all PCBs?
    A:NO MOQ,we do custom made PCB, and flexible PCB, depends on customers' projects.

    Q4. How do you ship the goods and how long does it take to arrive?
    A: For small quantity, we ship it by DHL, UPS, FedEx or TNT. It usually takes 3-5 days, and for big quantity needs 20-30 days by sea( the detail will be confirmed with the forwarder).

    Q5. I have no drawing, how to process it?
    A: Firstly let us know your detail requirements( if you have sample, please ship to us, we will copy it). Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

    Q6. Is it OK to print my logo on product?
    A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

    Q7: Do you offer guarantee for the products?
    A: Yes, we offer 1-3 years warranty to our products.

    Q8: How to deal with the faulty?
    A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.1%. Secondly, during the guarantee period, if it's our fault, we will repair them and resend to you or we can discuss the detail, and find the final solution.
